PI08-100-RRA-A-ABS33-Y224VDC
PI08-100-RRA-A
pinch valve series VF; directly operated; body aluminum; aluminum flange with steel socket; tube natural rubber; control pressure 1,8...2,5 bar higher than effective pressure; medium temperature -10...+80 °C; DN 100mm; operating pressure 0-6bar; flange connection PN10/16; length 280mm; control port 1/4"; ATEX, I M2 / II 2GD II C TX
ABS33-Y224VDC
ABS33
mounted pilot valve series ABS; silencer; suitable for pinch valves series PI08, series VF; connector size 32mm; 3/2-Wegemagnetventil (31A2FV15-U); standard coil BDA
Y224VDC
Solenoid coil Type Y2, ATEX- II 2G Ex mb IIC T4 / II 2D Ex mb tb IIIC T130°C; Cable length 3 m; Tension 24VDC-ATEX-Ex; Medium temperature max. 80°C
Country of origin: Germany
Weight: 1.12 Kg
Short Itemnumber:PI08100RRAAABS33Y224VDC
PI08-100-RRA-A
pinch valve series VF; directly operated; body aluminum; aluminum flange with steel socket; tube natural rubber; control pressure 1,8...2,5 bar higher than effective pressure; medium temperature -10...+80 °C; DN 100mm; operating pressure 0-6bar; flange connection PN10/16; length 280mm; control port 1/4"; ATEX, I M2 / II 2GD II C TX
ABS33-Y224VDC
ABS33
mounted pilot valve series ABS; silencer; suitable for pinch valves series PI08, series VF; connector size 32mm; 3/2-Wegemagnetventil (31A2FV15-U); standard coil BDA
Y224VDC
Solenoid coil Type Y2, ATEX- II 2G Ex mb IIC T4 / II 2D Ex mb tb IIIC T130°C; Cable length 3 m; Tension 24VDC-ATEX-Ex; Medium temperature max. 80°C
Specifications
| Design | ATEX |
