CVTE-15-NC-040-ABS89-MA22-24VDC-C002-31-6
CVTE-15-NC-040
2/2-way coaxial valve; externally controlled; G3/4"; 0…16bar; DN15; NC; body: stainless steel; medium: nitrogen; incl. 2 inductive limit switches OPEN/CLOSED (B); special seals; complete stainless steel; seals FDA-approved; incl. inspection certificate 3.1; incl. material certificate; special version
ABS89
mounted pilot valve; speed control; suitable for 2/2-way coaxial valve and 3/2-way-coaxial valve; externally controlled; DN15...DN50; standard coil MA22; connector size 22mm; 5/2-way solenoid valve - NAMUR type (MNH 510 701); body Aluminium; temperature range -10...+50°C
MA22-24VDC
coil; connector size 22mm; voltage 24VDC
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
Country of origin: Germany
Weight: 5.751 Kg
