BA835-65-02-S0-ABS53-C001-03-C002-31-6-EB0X02
BA835-65-02-S0
Flanged ball valve with pneumatic actuator Series BA835-S0; 3-way-type; Sealing on three ports; Body 1.4404 Polished; Ball 1.4404; Seals PTFE/FFKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 65mm; Length 240mm; Pressure range 0…16bar; Flange PN16; Actuator PAS1255; Ball T; Flow path 02
ABS53
Mounted pilot valve Series ABS; NAMUR; Silencer; Standard coil C001; Connector size 22mm; 3/2-way-NAMUR-Solenoid valve (NM32W1S-PR); Actuator PAS052-270
C001-03
Coil Type C001; Connector size 22mm; Voltage 24VDC / 48V/50-60Hz
C002-31-6
Connector; Connector size 22mm; Standard; Voltage 0-250VAC/DC
EB0X02
Mounted limit switch box; IP65; 2 Micro switches; Suitable for Actuators PAD/PAS052-270; Switching capacity 100mA/24VDC; Switch type Crouzet 831618; Contact material Alloy of gold; Material of case Plastic
Country of origin: Italy
Weight: 38.458 Kg
Short Itemnumber:BA8356502S0ABS53C00103C002316EB0X02
BA835-65-02-S0
flanged ball valve with pneumatic actuator series BA835-S0; 3-way-type; sealing on three ports; body AISI 316L polished; ball AISI 316L; seals PTFE/FFKM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; nominal diameter 65mm; length 240mm; pressure range 0…16bar; flange PN16; actuator PAS1255; ball T; flow path 02
ABS53
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 3/2-way-NAMUR-solenoid valve (NM32W1S-PR); actuator PAS052-270
C001-03
coil type C001; connector size 22mm; voltage 24VDC / 48V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC
EB0X02
mounted limit switch box; IP65; 2 micro switches; suitable for actuators PAD/PAS052-270; switching capacity 100mA/24VDC; switch type Crouzet 831618; contact material alloy of gold; material of case plastic
