BA410-38-S0-ABS53-C001-22-C002-31-6

BA410-38-S0-ABS53-C001-22-C002-31-6

BA410-38-S0
Ball valve with pneumatic actuator; Female thread; Body, Ball 1.4401; Seals PTFE-Reinforced with carbographite/EPDM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -40...+160°C; With additional compensation hole in the ball; RP 3/8"; Nominal diameter 10mm; Pressure range 0-64bar; Length 57mm; Actuator PAS0525
ABS53
Mounted pilot valve Series ABS; NAMUR; Silencer; Standard coil C001; Connector size 22mm; 3/2-way-NAMUR-Solenoid valve (NM32W1S-PR); Actuator PAS052-270
C001-22
Coil Type C001; Connector size 22mm; Voltage 230V/50-60Hz
C002-31-6
Connector; Connector size 22mm; Standard; Voltage 0-250VAC/DC

Intrastat No.: 84818081
Country of origin: Italy
Weight: 2.013 Kg
Short Itemnumber:BA41038S0ABS53C00122C002316
https://infotainment-tirol.at/web/image/product.template/211684/image_1920?unique=07bf1b6

BA410-38-S0
ball valve with pneumatic actuator; female thread; body, ball AISI 316; seals PTFE-reinforced with carbographite/EPDM; single acting actuator; control pressure 5,5...8bar; medium temperature -40...+160°C; with additional compensation hole in the ball; RP 3/8"; nominal diameter 10mm; pressure range 0-64bar; length 57mm; actuator PAS0525
ABS53
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 3/2-way-NAMUR-solenoid valve (NM32W1S-PR); actuator PAS052-270
C001-22
coil type C001; connector size 22mm; voltage 230V/50-60Hz
C002-31-6
connector; connector size 22mm; Standard; voltage 0-250VAC/DC

518,69 € 518.6899999999999 EUR 518,69 €

Not Available For Sale
