BA368-40-S0-A-ABS53-PI10-EPC02400-1-EB0X05
BA368-40-S0-A
flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T3; fire-safe; TA-Luft; length according to EN558−1R27; body, ball AISI 316; seals TFM-MPTFE/Graphoil/V-Pack PTFE; single acting actuator; control pressure 5,5...8bar; medium temperature -40...+180°C; nominal diameter 40mm; pressure range 0...40bar; flange PN40; length 140mm; actuator PAS0855
ABS53-PI10
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 3/2-Wege-NAMUR-Magnetventil (NM32W1S-PR); actuator PAS052-270; connection 10mm
EPC02400-1
mounted coil type EPC; ATEX- II 2G Ex mb IIC T5 Gb / II 2D Ex tb IIIC T95°C IP66 Db; cable length 3m; voltage 24VDC
EB0X05
mounted limit switch box; IP65; 2 micro switches; suitable for actuators PAD/PAS052-270; switching capacity 4A/250VAC-1A/24VDC; switch type Crouzet 831391 - ATEX; contact material Silber-Nickel; material of case plastic
Country of origin: Italy
Weight: 14.684 Kg
Short Itemnumber:BA36840S0AABS53PI10EPC024001EB0X05
BA368-40-S0-A
flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T3; fire-safe; TA-Luft; length according to EN558−1R27; body, ball AISI 316; seals TFM-MPTFE/Graphoil/V-Pack PTFE; single acting actuator; control pressure 5,5...8bar; medium temperature -40...+180°C; nominal diameter 40mm; pressure range 0...40bar; flange PN40; length 140mm; actuator PAS0855
ABS53-PI10
mounted pilot valve series ABS; NAMUR; silencer; standard coil C001; connector size 22mm; 3/2-Wege-NAMUR-Magnetventil (NM32W1S-PR); actuator PAS052-270; connection 10mm
EPC02400-1
mounted coil type EPC; ATEX- II 2G Ex mb IIC T5 Gb / II 2D Ex tb IIIC T95°C IP66 Db; cable length 3m; voltage 24VDC
EB0X05
mounted limit switch box; IP65; 2 micro switches; suitable for actuators PAD/PAS052-270; switching capacity 4A/250VAC-1A/24VDC; switch type Crouzet 831391 - ATEX; contact material Silber-Nickel; material of case plastic
Specifications
| Design | ATEX |
