BA056-100-3S0-ABS53-PI12-C001-03-C002-31-6-EB0X01
BA056-100-3S0
Flanged ball valve with pneumatic rotary actuator Series BA055, BA056; 3-way version; Three-shell sealing; Housing 1.4404 Polished; Ball 1.4404; Seals PTFE/FKM; Single-acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 100mm; Installation length 300mm; Print area 0…16bar; Flange PN16; Drive PAS1605; Ball bore T; Switching mode 03
ABS53-PI12
Mounted control valve Series ABS; NAMUR; Silencer; Standard coil C001; Plug width 22mm; 3/2-Wege-NAMUR-Magnetventil (NM32W1S-PR); Drive PAS052-270; Connection 12mm
C001-03
Solenoid coil Type C001; Plug width 22mm; Tension 24VDC / 48V/50-60Hz
C002-31-6
Cable plug; Plug width 22mm; Standard; Tension 0-250VAC/DC
EB0X01
Mounted limit switch box; IP65; 2 Microswitch; suitable for Drives PAD/PAS052-270; Switching capacity 4A/250VAC-1A/24VDC; Switch type Crouzet 831613; Contact material Silver-nickel; Housing material Plastic
Country of origin: Italy
Weight: 80.379 Kg
Short Itemnumber:BA0561003S0ABS53PI12C00103C002316EB0X01
BA056-100-3S0
Flanged ball valve with pneumatic rotary actuator Series BA055, BA056; 3-way version; Three-shell sealing; Housing 1.4404 Polished; Ball 1.4404; Seals PTFE/FKM; Single-acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Nominal diameter 100mm; Installation length 300mm; Print area 0…16bar; Flange PN16; Drive PAS1605; Ball bore T; Switching mode 03
ABS53-PI12
Mounted control valve Series ABS; NAMUR; Silencer; Standard coil C001; Plug width 22mm; 3/2-Wege-NAMUR-Magnetventil (NM32W1S-PR); Drive PAS052-270; Connection 12mm
C001-03
Solenoid coil Type C001; Plug width 22mm; Tension 24VDC / 48V/50-60Hz
C002-31-6
Cable plug; Plug width 22mm; Standard; Tension 0-250VAC/DC
EB0X01
Mounted limit switch box; IP65; 2 Microswitch; suitable for Drives PAD/PAS052-270; Switching capacity 4A/250VAC-1A/24VDC; Switch type Crouzet 831613; Contact material Silver-nickel; Housing material Plastic
